The Edge 3 Stretto® is the narrowest, most maneuverable power base in America! This narrow wheelchair base is perfect for navigating tight corners and small spaces. With an overall width of 20.47” with 12.5” drive wheels, the Stretto® is the best narrow wheelchair for children, teenagers and small adults to use in the home. The Stretto® is available with 12.5” or 14” drive wheels and optional 12” of iLevel® power adjustable seat height.
In addition to its narrow width, the Edge 3 Stretto® is equipped with independent SRS (Smooth Ride Suspension), which offers increased shock absorption due to the angle of the shocks. Enjoy maximum obstacle climbing and increased overall comfort.
The Edge 3 Stretto® Power Chair is iLevel Ready!
Over 40,000 lives enabled with iLevel…
and rising!
| Model | Q6 Edge 3 Stretto® |
| Drive Configuration | Mid-wheel drive |
| Drive Wheels | 14" or 12.5" Pneumatic or flat free tires |
| Caster Wheels | Front: 5" flat free Rear: 6" flat free |
| Maximum Speed4,13 | Up to 6.25 mph Up to 3.5 mph with iLevel activated |
| Ground Clearance | 2.9" |
| Turning Radius5 | 21" |
| Overall Length11 | 32.5" without front riggings |
| Base Width | 21.75" with 14" drive wheels 20.47" with 12.5" drive wheels |
| Seating Sizes | TRU-Balance® 3 Static Seat: W: 12-20" D: 12-20" Power Tilt: W: 12-20" D: 12-20" Tilt & iLevel: W: 12-20" D: 12-20" Flex Seating: W: 15-20" D: 15-20" |
| Seat-to-Floor Heights16,17 | TRU-Balance® 3 Static Seat8: 16-18" Power Tilt8: 17.5-19.5" Tilt & iLevel8: 17.5-19.5" Flex Seating8: 16.5-18.25" |
| Battery Size6 | 40 AH (2) or NF-22 (2) |
| Battery Weight14 | 40 AH: 31 lbs. each 55 AH: 40 lbs. each |
| Available Electronics12 | 120A Q-Logic 3 EX 120A Q-Logic 3e 75A Q-Logic NE 75A Q-Logic NE+ |
| Battery Charger | 8A off-board |
| Motor Packages | 2-pole, Mid-Wheel® 6 |
| Weight Capacity7 | 300 lbs. |
| Base Weight | 126.4 lbs. |
| Medicare Code Coverage | Group 3: Standard (K0848) Single Power (K0856/K0867) Multiple Power (K0861) |
| Notes: 4 Speed varies with user weight, terrain type, battery charge, battery condition and tire pressure. 5 Without front riggings 6 Battery capacity may change when adding power positioning systems. 7 Weight capacity is dictated by the selection of seating. 8 All measurement +/- 1/8" with 18" x 18" seat, fixed towers, 300 lbs. weight capacity and solid tires (add 3/8" with pneumatic tires). Depths may increase seat-to-floor height. Contact Customer Service for details. Limited measurements are in the lowest position; does not include elevating system unless specified. 11 Without foot riggings 12 All Quantum Rehab® units can be ordered with specialty controls 13 6.25 mph speed available only with Q-Logic 3 14 Battery weight may vary +/- 3 lbs. based on manufacturer. 16 Seat-to-floor heights are measured with the unit unloaded. Due to the 4Front’s suspension system, seat-to-floor heights are approximately 0.25” lower when the unit is loaded. 17 16.5" seat-to-floor height is not available with power tilt or iLevel®. 19.5" seat-to-floor height is not available with static seat or power recline. |
|
